AMPLIFIER SECTION:
Power Output (8 Ω, 20 Hz-20 kHz, FTC) 100W / Channel (8 Ω)
Dynamic Power 240W / Channel (3 Ω)
210W / Channel (4 Ω)
120W / Channel (8 Ω)
THD (Total Harmonic Distortion + Noise) 0.08% (20 Hz-20 kHz, Half Power)
Input Sensitivity and Impedance 200 mV / 47 k-Ω (LINE)
3.5 mV / 47 k-Ω (Phono MM)
Rated RCA Output Level and Impedance 1 Vrms / 470 Ω (Subwoofer Pre Out)
200 mV / 2.3 k-Ω (Zone Pre / Line Out)
2.0 V / 2.3 k-Ω (Zone Pre Out)
Phono Overload 70 mV (MM 1 kHz, 1%)
Frequency Response 5 Hz - 100 kHz / +1 dB-3 dB
Tone Control ±10dB, 90 Hz (Bass)
±10dB, 7.5 kHz (Treble)
Signal-to-Noise Ratio 106 dB (Line, IHF-A)
80 dB (Phono)
Speaker Impedance 4 Ω - 16 Ω
VIDEO SECTION:
Input Sensitivity / Output Level and Impedance 1.0 Vp-p / 75 Ω (Component Y)
0.7 Vp-p / 75 Ω (Component Pb/Cb, Pr/Cr)
1.0 Vp-p / 75 Ω (Composite)
TUNER SECTION:
Tuning Frequency Range FM 87.5 MHz - 107.9 MHz
AM 530 kHz - 1,710 kHz
FM / AM Preset Memory 40 Stations
GENERAL:
Power Supply AC 120 V, 60 Hz
Power Consumption 580 W
Stand-by Power Consumption 0.15 W
Dimensions (W X H X D) 17 1/8" x 6 7/8" x 14 13/16"
435 x 174 x 376.5 mm
Weight 23.1 lbs. (10.5 kg)
CARTON:
Dimensions (W X H X D) 22 7/16" x 11 3/4" x 18 7/16"
570 x 298 x 469 mm
Weight 29.8 lbs. (13.5 kg)
阿強家庭影院導購 網歡迎您，tdntmepa.cn 微信公眾號：hdkong
AMPLIFIER:
# Channels 7.2
POWER (8 Ω 20-20kHz 0.08%) / CH 100
Amplifier Frequency Response 5Hz - 100kHz
Wide Range, High Current Power Supply Natural Harmonics Technology, Massive High-Power Transformer
High Instanteneous Current Capability 30 Amps, 1kHz, 00.1 Ω Pulse
THX Certified
Continuous 6 Ω Rated ✓
Low Impedance Drive- Certified 4 Ω ✓
Hand Selected Parts to Ensure Low Impedance Performance Custom- Audio Tuned
Discrete Output Stages for All Channels Discrete 2-Stage
All Channels Equal Power Output ✓
PUSH-PULL Amplifier Design ✓
Independent Power Supply 2
Bi-amp Capability - Front L/R Channels ✓
PROCESSING:
Dolby Atmos and Dolby Surround ✓
Dolby TrueHD ✓
DTS:X and DTS Neural:X ✓
DTS-HD Master Audio ✓
THX Processing Modes & Loudness Plus
VLSC for Noise Free Signal Path Front Left / Right Channels
AccuEQ Automatic Room Calibration Advanced w/AccuReflex
GAME Surround Modes (Rock, Action, Sports, Role Play) ✓
Advanced Music Optimizer to Enhance Compressed Audio Files ✓
Premium Quality Digital-to-Analog Conversion 384k / 32-bit AKM4458 Differential DAC
32-Bit DSP Chip for Advanced Processing ✓
Ultra-Low-Jitter Circuitry to Improve Audio ✓
Adjustable Crossover by Channel Pair 40/45/50/55/60/70/80/90
100/110/120/130/150/180/200 Hz
Accurate Speaker Distance Setting 0.1 - foot
A/V Sync Delay (by Source) -100 to +500 ms
CONNECTIVITY:
HDMI Inputs / Output(s) 7 / 2
4K / 60 Hz 4:4:4 Colorspace Support ✓
HDCP 2.2 Copy-Protection Compatibility ✓
Dolby Vision Support ✓
HLG (Hybrid Log Gamma), HDR10, WCG (Wide Color Gamut) Support ✓
HDMI Support for BT.2020 ✓
HDMI Support for 3D, Audio Return Channel and CEC ✓
HDMI Support for Deep Color, x.v.Color, LipSync ✓
HDMI Support for DVD-Audio, SACD, Multichannel PCM ✓
Front Panel HDMI Input ✓
HDBaseT Output
Analog to HDMI Upconversion From 480i / 576i
Component Video Inputs 2
Composite Video Inputs 2
Digital Audio Inputs (COAX / OPT) 1 / 2
Analog Audio Inputs 8
Phono Input ✓
Front Panel A/V Input ✓
Analog Pre-outs 7.2
NETWORK / USB:
Google Chromecast built-in ✓
Google Assistant (Voice Control) X
FireConnect Wireless Mult-Room Audio Streaming Technlogy ✓
DTS Play-Fi ✓ (Future Firmware Update)
App Control via iOS and Android-Powered Devices Integra Control Pro
Apple Airplay ✓
iPod / iPhone / iPad Ready ✓
Home Network Music Streaming ✓
TIDAL High Fidelity Music Streaming ✓
Pandora ✓
Spotify ✓
Spotify Connect ✓
TuneIn Radio ✓
Deezer ✓
DSD Support (2.8, 5.6, 11.2 MHz) ✓
Dolby TrueHD Support ✓
Apple Losless (ALAC) Support ✓
WAV Support ✓
AIFF Support ✓
DSDIFF Support ✓
FLAC Support ✓
MP3 Support ✓
USB Input for Streaming Audio ✓
WiFi Certified IEEE 802.11 a/b/g/n
5 Ghz / 2.4 Ghz
Bluetooth Built-in
Firmware Updates via Network and USB ✓
MULTIZONE:
Powered Zone 2 ✓
Powered Zone 2 A / B
Powered Zone 3
Fixed or Variable Zone 2 Line Out ✓
Fixed or Variable Zone 3 Line Out
Zone 2 Video Output
Zone 2 OSD
Zone 2 Audio DAC SPDIF, NET, USB
Zone 3 Audio DAC
Whole House Mode
INTEGRATION ACCESS:
Bi-directional RS-232 Control Port ✓
Bi-directional Ethernet Control Port ✓
Rear Panel IR Input / Output 2 / 1
RIHD (Remote Interactive over HDMI) ✓
12V Trigger (with Adjustable delay) x3, Assignable
MISCELLANEOUS:
GUI for Setup Menu ✓ (Advanced HD)
Quick Setup Menu ✓
Input Name Edit Fully Customizable
HDMI Standby "Through" Mode Assignable
Dealer Settings Memory Store & Recall Function ✓
Screensaver Function ✓ (Advanced)
Hybrid Standby to Reduce Power Consumption ✓
Smart Grid Ready ✓
Anti-Resonant Aluminum Front Panel ✓
Gold-Plated RCA Terminals ✓
Oversized Detachable AC Cord ✓
